RE: [wtp-dev] The Big Picture
|
Hi Konstantin,
Thanks for building this tool - the
graphs really help to provide an overview of the dependencies and should
generate some good discussion. I also have a home brew tool that scans
for dependencies and provides information on references, calculates install
sizes, etc., so maybe we can find a way to collaborate.
> I
then ran my utility against 3.0 M1 installation which included WTP SDK
and WTP automated tests.
We may want to compare without test
plugins as well - I know in some cases teams have built test harnesses
that aren't strictly component specific, e.g. a test that extends WTP like
an adopter to test extension points and interactions across components.
We'll need to examine these dependencies to understand if they are valid,
mistakes, or if there is some restructuring that should occur. All of this
should be done in light of the installable options we want to provide in
addition to our current features and new component definitions.
I have to send my regrets for today's
call, but David will be announcing the formation of an Architecture Working
Group. I'll setup a call next week so that we can start talking about these
issues, update our current docs, and decide what work needs to be done.
Thanks,
Tim deBoer
deboer@xxxxxxxxxx
"Konstantin Komissarchik"
<kosta@xxxxxxx>
Sent by: wtp-dev-bounces@xxxxxxxxxxx
09/04/2007 09:27 PM
Please respond to
"General discussion of project-wide or architectural issues."
<wtp-dev@xxxxxxxxxxx> |
|
To
| "General discussion of project-wide
or architectural issues." <wtp-dev@xxxxxxxxxxx>
|
cc
|
|
Subject
| RE: [wtp-dev] The Big Picture |
|
One of my goal was to better understand
the new organization as specified by the project refactoring proposal,
so using existing features would not work for that since they have yet
to be updated to reflect this. Part of this process (at least as far as
it applies to common) is to drive the creation of new features.
So... If you look at the component
listings in my e-mail, you will notice that WST and JST parts co-mingle
(just like they do in the project refactoring proposal). Now, if under
each of the new projects we define a WST and a JST component and graph
dependencies of those components, then we would not end up with any cycles
(the build works, as you point out). Is that good enough? Is it ok to have
cycles at project-level as long as we can define components such as no
cycles would exists? How would you build such a structure once the codebase
is re-organized based on the project refactoring proposal? We wouldn't
be able to have a project-level build since a top-level driver would need
to know how to weave builds of components of different projects such that
cycles are avoided.
The Java EE <-> Common cycle
is due to jst.common.frameworks depending on wst.web. This seems wrong
to me. This builds right now because by the time jst.common builds, all
of wst has been compiled, but I think jst.common should only be able to
see wst.common.
- Konstantin
From: wtp-dev-bounces@xxxxxxxxxxx
[mailto:wtp-dev-bounces@xxxxxxxxxxx] On Behalf Of David M Williams
Sent: Tuesday, September 04, 2007 5:57 PM
To: General discussion of project-wide or architectural issues.
Subject: Re: [wtp-dev] The Big Picture
I'm not sure I understand, but if you are saying that Common depends on
Java EE, then I think something is amiss.
The way our build works, it wouldn't compile if that was the case.
Does your analysis also take into account the WST/JST split?
I think the way to approach this would be more along the lines of our defined
features?
Or, am I simply not understanding?
thanks,
"Konstantin Komissarchik"
<kosta@xxxxxxx>
Sent by: wtp-dev-bounces@xxxxxxxxxxx
09/04/2007 08:19 PM
Please respond to
"General discussion of project-wide or architectural issues."
<wtp-dev@xxxxxxxxxxx> |
|
To
| "General discussion of
project-wide or architectural issues." <wtp-dev@xxxxxxxxxxx>
|
cc
|
|
Subject
| [wtp-dev] The Big Picture |
|
So in my quest to understand the "Common Project", I've been
writing a little utility that can analyze plugin dependencies and produce
a component-to-component dependencies (given component definitions). Until
today, I've been mostly focused on understanding how the rest of WTP depends
on common, but today I decided to let my utility show me the rest of the
picture. Attached is the result.
I knew the dependency lines were not going to be clean, but I was a bit
surprised by the result. There are four simple circles that can be easily
spotted...
Java EE <-> Common (yikes!)
Java EE <-> EJB
Java EE <-> Server Tools
Java EE <-> Web Services
More complicated circles are also present, but these are harder to spot.
One example is Web Services -> EJB -> Java EE -> Web Services.
It strikes me that we either have a lot of work ahead of us on refactoring
the dependencies or these boxes aren't quite right. Maybe a bit of both.
Thoughts? Does any of this come as a surprise?
I used information found in http://www.eclipse.org/webtools/devProcess/wtpProjects/Refactor%20WTP%20Proposal.pdf
as the definition of the component boundaries. I then ran my utility against
3.0 M1 installation which included WTP SDK and WTP automated tests. Let
me know if the component membership as listed is not accurate and needs
to be tweaked. The only two plugins that are not accounted for are org.eclipse.wst
and org.eclipse.jst. Not sure where these would end up.
Common Component
org.eclipse.jem
org.eclipse.jem.beaninfo
org.eclipse.jem.proxy
org.eclipse.jem.tests
org.eclipse.jem.ui
org.eclipse.jem.util
org.eclipse.jem.workbench
org.eclipse.jst.common.annotations.controller
org.eclipse.jst.common.annotations.core
org.eclipse.jst.common.annotations.ui
org.eclipse.jst.common.frameworks
org.eclipse.jst.common.project.facet.core
org.eclipse.jst.validation.sample
org.eclipse.jst.validation.test
org.eclipse.wst.command.env
org.eclipse.wst.command.env.core
org.eclipse.wst.command.env.doc.user
org.eclipse.wst.command.env.infopop
org.eclipse.wst.command.env.ui
org.eclipse.wst.common.core
org.eclipse.wst.common.emf
org.eclipse.wst.common.emfworkbench.integration
org.eclipse.wst.common.environment
org.eclipse.wst.common.frameworks
org.eclipse.wst.common.frameworks.ui
org.eclipse.wst.common.infopop
org.eclipse.wst.common.modulecore
org.eclipse.wst.common.project.facet.core
org.eclipse.wst.common.project.facet.core.tests
org.eclipse.wst.common.project.facet.ui
org.eclipse.wst.common.project.facet.ui.tests
org.eclipse.wst.common.snippets
org.eclipse.wst.common.snippets.tests
org.eclipse.wst.common.tests
org.eclipse.wst.common.tests.collector
org.eclipse.wst.common.tests.ui
org.eclipse.wst.common.ui
org.eclipse.wst.common.ui.properties
org.eclipse.wst.common.uriresolver
org.eclipse.wst.internet.cache
org.eclipse.wst.internet.cache.tests
org.eclipse.wst.validation
org.eclipse.wst.validation.infopop
org.eclipse.wst.validation.ui
Server Component
org.eclipse.jst.server.core
org.eclipse.jst.server.core.tests
org.eclipse.jst.server.generic.core
org.eclipse.jst.server.generic.jboss
org.eclipse.jst.server.generic.jonas
org.eclipse.jst.server.generic.oc4j
org.eclipse.jst.server.generic.tests
org.eclipse.jst.server.generic.ui
org.eclipse.jst.server.installable
org.eclipse.jst.server.preview.adapter
org.eclipse.jst.server.tomcat.core
org.eclipse.jst.server.tomcat.core.tests
org.eclipse.jst.server.tomcat.ui
org.eclipse.jst.server.tomcat.ui.tests
org.eclipse.jst.server.ui
org.eclipse.jst.server.ui.doc.user
org.eclipse.jst.server.ui.infopop
org.eclipse.jst.server.ui.tests
org.eclipse.jst.server.websphere.core
org.eclipse.wst.internet.monitor.core
org.eclipse.wst.internet.monitor.ui
org.eclipse.wst.internet.monitor.ui.tests
org.eclipse.wst.server.core
org.eclipse.wst.server.core.tests
org.eclipse.wst.server.http.core
org.eclipse.wst.server.http.core.tests
org.eclipse.wst.server.http.ui
org.eclipse.wst.server.preview
org.eclipse.wst.server.preview.adapter
org.eclipse.wst.server.ui
org.eclipse.wst.server.ui.doc.user
org.eclipse.wst.server.ui.infopop
org.eclipse.wst.server.ui.tests
Source Editors Component
org.eclipse.jst.jsp.core
org.eclipse.jst.jsp.core.tests
org.eclipse.jst.jsp.tests.encoding
org.eclipse.jst.jsp.ui
org.eclipse.jst.jsp.ui.infopop
org.eclipse.jst.jsp.ui.tests
org.eclipse.jst.standard.schemas
org.eclipse.wst.css.core
org.eclipse.wst.css.core.tests
org.eclipse.wst.css.tests.encoding
org.eclipse.wst.css.ui
org.eclipse.wst.css.ui.tests
org.eclipse.wst.dtd.core
org.eclipse.wst.dtd.ui
org.eclipse.wst.dtd.ui.infopop
org.eclipse.wst.dtd.ui.tests
org.eclipse.wst.dtdeditor.doc.user
org.eclipse.wst.html.core
org.eclipse.wst.html.core.tests
org.eclipse.wst.html.tests.encoding
org.eclipse.wst.html.ui
org.eclipse.wst.html.ui.infopop
org.eclipse.wst.html.ui.tests
org.eclipse.wst._javascript_.core
org.eclipse.wst._javascript_.ui
org.eclipse.wst._javascript_.ui.infopop
org.eclipse.wst.sse.core
org.eclipse.wst.sse.core.tests
org.eclipse.wst.sse.doc.user
org.eclipse.wst.sse.ui
org.eclipse.wst.sse.ui.infopop
org.eclipse.wst.sse.ui.tests
org.eclipse.wst.standard.schemas
org.eclipse.wst.xml.core
org.eclipse.wst.xml.core.tests
org.eclipse.wst.xml.tests.encoding
org.eclipse.wst.xml.ui
org.eclipse.wst.xml.ui.infopop
org.eclipse.wst.xml.ui.tests
org.eclipse.wst.xml.validation.tests
org.eclipse.wst.xmleditor.doc.user
org.eclipse.wst.xsd.core
org.eclipse.wst.xsd.ui
org.eclipse.wst.xsd.validation.tests
org.eclipse.wst.xsdeditor.doc.user
Web Services Component
org.eclipse.jst.ws
org.eclipse.jst.ws.axis.consumption.core
org.eclipse.jst.ws.axis.consumption.core.tests
org.eclipse.jst.ws.axis.consumption.ui
org.eclipse.jst.ws.axis.creation.ui
org.eclipse.jst.ws.axis.infopop
org.eclipse.jst.ws.axis.ui.doc.user
org.eclipse.jst.ws.axis2.consumption.core
org.eclipse.jst.ws.axis2.consumption.ui
org.eclipse.jst.ws.axis2.core
org.eclipse.jst.ws.axis2.creation.core
org.eclipse.jst.ws.axis2.creation.ui
org.eclipse.jst.ws.axis2.ui
org.eclipse.jst.ws.consumption
org.eclipse.jst.ws.consumption.infopop
org.eclipse.jst.ws.consumption.ui
org.eclipse.jst.ws.consumption.ui.doc.user
org.eclipse.jst.ws.creation.ejb.ui
org.eclipse.jst.ws.creation.ui
org.eclipse.jst.ws.doc.user
org.eclipse.jst.ws.infopop
org.eclipse.jst.ws.tests
org.eclipse.jst.ws.uddiregistry
org.eclipse.jst.ws.ui
org.eclipse.wst.ws
org.eclipse.wst.ws.explorer
org.eclipse.wst.ws.infopop
org.eclipse.wst.ws.parser
org.eclipse.wst.ws.tests
org.eclipse.wst.ws.ui
org.eclipse.wst.wsdl
org.eclipse.wst.wsdl.tests
org.eclipse.wst.wsdl.tests.ui
org.eclipse.wst.wsdl.ui
org.eclipse.wst.wsdl.ui.doc.user
org.eclipse.wst.wsdl.validation
org.eclipse.wst.wsdl.validation.tests
org.eclipse.wst.wsi
org.eclipse.wst.wsi.tests
org.eclipse.wst.wsi.ui
org.eclipse.wst.wsi.ui.doc.user
Java EE Tools Component
org.eclipse.jst.doc.isv
org.eclipse.jst.j2ee
org.eclipse.jst.j2ee.core
org.eclipse.jst.j2ee.core.tests
org.eclipse.jst.j2ee.doc.user
org.eclipse.jst.j2ee.infopop
org.eclipse.jst.j2ee.jca
org.eclipse.jst.j2ee.jca.ui
org.eclipse.jst.j2ee.navigator.ui
org.eclipse.jst.j2ee.tests
org.eclipse.jst.j2ee.ui
org.eclipse.jst.j2ee.web
org.eclipse.jst.j2ee.webservice
org.eclipse.jst.j2ee.webservice.ui
org.eclipse.jst.j2ee.xdoclet.runtime
org.eclipse.jst.jee
org.eclipse.jst.jee.ui
org.eclipse.jst.jee.web
org.eclipse.jst.servlet.tests
org.eclipse.jst.servlet.ui
org.eclipse.jst.servlet.ui.infopop
org.eclipse.wst.doc.isv
org.eclipse.wst.doc.user
org.eclipse.wst.web
org.eclipse.wst.web.ui
org.eclipse.wst.web.ui.infopop
org.eclipse.wst.webtools.doc.user
EJB Tools Component
org.eclipse.jst.ejb.doc.user
org.eclipse.jst.ejb.ui
org.eclipse.jst.j2ee.ejb
org.eclipse.jst.j2ee.ejb.annotation.model
org.eclipse.jst.j2ee.ejb.annotations.emitter
org.eclipse.jst.j2ee.ejb.annotations.ui
org.eclipse.jst.j2ee.ejb.annotations.xdoclet
org.eclipse.jst.jee.ejb
JSF Component
org.eclipse.jst.jsf.common
org.eclipse.jst.jsf.common.ui
org.eclipse.jst.jsf.contentassist.tests
org.eclipse.jst.jsf.context.symbol.tests
org.eclipse.jst.jsf.core
org.eclipse.jst.jsf.core.tests
org.eclipse.jst.jsf.designtime.tests
org.eclipse.jst.jsf.doc.dev
org.eclipse.jst.jsf.doc.user
org.eclipse.jst.jsf.facesconfig
org.eclipse.jst.jsf.facesconfig.ui
org.eclipse.jst.jsf.metadata.tests
org.eclipse.jst.jsf.metadataprocessingtests2
org.eclipse.jst.jsf.standard.tagsupport
org.eclipse.jst.jsf.test.util
org.eclipse.jst.jsf.ui
org.eclipse.jst.jsf.ui.tests
org.eclipse.jst.pagedesigner
org.eclipse.jst.pagedesigner.jsf.ui
org.eclipse.jst.pagedesigner.jsp.core
JPT Component
org.eclipse.jpt
org.eclipse.jpt.core
org.eclipse.jpt.core.tests
org.eclipse.jpt.core.tests.extension.resource
org.eclipse.jpt.db
org.eclipse.jpt.db.ui
org.eclipse.jpt.doc.user
org.eclipse.jpt.gen
org.eclipse.jpt.ui
org.eclipse.jpt.utility
org.eclipse.jpt.utility.tests
Notice: This email message, together with any attachments, may contain
information of BEA Systems, Inc., its subsidiaries and affiliated entities,
that may be confidential, proprietary, copyrighted and/or legally privileged,
and is intended solely for the use of the individual or entity named in
this message. If you are not the intended recipient, and have received
this message in error, please immediately return this by email and then
delete it._______________________________________________
wtp-dev mailing list
wtp-dev@xxxxxxxxxxx
https://dev.eclipse.org/mailman/listinfo/wtp-dev
Notice: This email message, together with any attachments, may contain
information of BEA Systems, Inc., its subsidiaries and affiliated entities,
that may be confidential, proprietary, copyrighted and/or legally privileged,
and is intended solely for the use of the individual or entity named in
this message. If you are not the intended recipient, and have received
this message in error, please immediately return this by email and then
delete it._______________________________________________
wtp-dev mailing list
wtp-dev@xxxxxxxxxxx
https://dev.eclipse.org/mailman/listinfo/wtp-dev
