RE: [wtp-dev] The Big Picture
|
One of my goal was to better understand the new
organization as specified by the project refactoring proposal, so using existing
features would not work for that since they have yet to be updated to reflect
this. Part of this process (at least as far as it applies to common) is to drive
the creation of new features.
So... If you look at the component listings in my
e-mail, you will notice that WST and JST parts co-mingle (just like they do in
the project refactoring proposal). Now, if under each of the new projects we
define a WST and a JST component and graph dependencies of those components,
then we would not end up with any cycles (the build works, as you point out). Is
that good enough? Is it ok to have cycles at project-level as long as we can
define components such as no cycles would exists? How would you build such a
structure once the codebase is re-organized based on the project refactoring
proposal? We wouldn't be able to have a project-level build since a top-level
driver would need to know how to weave builds of components of different
projects such that cycles are avoided.
The Java EE <-> Common cycle is due to
jst.common.frameworks depending on wst.web. This seems wrong to me. This builds
right now because by the time jst.common builds, all of wst has been compiled,
but I think jst.common should only be able to see
wst.common.
- Konstantin
From:
wtp-dev-bounces@xxxxxxxxxxx [mailto:wtp-dev-bounces@xxxxxxxxxxx] On Behalf Of
David M Williams
Sent: Tuesday, September 04, 2007 5:57
PM
To: General discussion of project-wide or architectural
issues.
Subject: Re: [wtp-dev] The Big Picture
I'm not sure I understand, but if
you are saying that Common depends on Java EE, then I think something is amiss.
The way our build works, it wouldn't
compile if that was the case. Does
your analysis also take into account the WST/JST split? I think the way to approach this would be more along the
lines of our defined features? Or,
am I simply not understanding? thanks,
"Konstantin Komissarchik"
<kosta@xxxxxxx>
Sent by:
wtp-dev-bounces@xxxxxxxxxxx
09/04/2007 08:19 PM
|
Please respond
to
"General discussion of project-wide or architectural issues."
<wtp-dev@xxxxxxxxxxx> |
|
|
To
| "General discussion of project-wide
or architectural issues." <wtp-dev@xxxxxxxxxxx>
|
|
cc
|
|
|
Subject
| [wtp-dev] The Big
Picture |
|
So in my quest to understand the "Common Project", I've been writing a
little utility that can analyze plugin dependencies and produce a
component-to-component dependencies (given component definitions). Until today,
I've been mostly focused on understanding how the rest of WTP depends on common,
but today I decided to let my utility show me the rest of the picture. Attached
is the result. I knew the dependency lines were not going to be clean, but I was a bit
surprised by the result. There are four simple circles that can be easily
spotted... Java EE <-> Common (yikes!) Java
EE <-> EJB Java EE <-> Server
Tools Java EE <-> Web Services
More complicated
circles are also present, but these are harder to spot. One example is Web
Services -> EJB -> Java EE -> Web Services. It strikes me that we either
have a lot of work ahead of us on refactoring the dependencies or these boxes
aren't quite right. Maybe a bit of both.
Thoughts? Does any of this come as a
surprise? I
used information found in http://www.eclipse.org/webtools/devProcess/wtpProjects/Refactor%20WTP%20Proposal.pdf as the definition of the component boundaries. I then ran my
utility against 3.0 M1 installation which included WTP SDK and WTP automated
tests. Let me know if the component membership as listed is not accurate and
needs to be tweaked. The only two plugins that are not accounted for are
org.eclipse.wst and org.eclipse.jst. Not sure where these would end up.
Common
Component
org.eclipse.jem
org.eclipse.jem.beaninfo
org.eclipse.jem.proxy
org.eclipse.jem.tests
org.eclipse.jem.ui
org.eclipse.jem.util
org.eclipse.jem.workbench
org.eclipse.jst.common.annotations.controller
org.eclipse.jst.common.annotations.core
org.eclipse.jst.common.annotations.ui
org.eclipse.jst.common.frameworks
org.eclipse.jst.common.project.facet.core
org.eclipse.jst.validation.sample
org.eclipse.jst.validation.test
org.eclipse.wst.command.env
org.eclipse.wst.command.env.core
org.eclipse.wst.command.env.doc.user
org.eclipse.wst.command.env.infopop
org.eclipse.wst.command.env.ui
org.eclipse.wst.common.core
org.eclipse.wst.common.emf
org.eclipse.wst.common.emfworkbench.integration
org.eclipse.wst.common.environment
org.eclipse.wst.common.frameworks
org.eclipse.wst.common.frameworks.ui
org.eclipse.wst.common.infopop
org.eclipse.wst.common.modulecore
org.eclipse.wst.common.project.facet.core
org.eclipse.wst.common.project.facet.core.tests
org.eclipse.wst.common.project.facet.ui
org.eclipse.wst.common.project.facet.ui.tests
org.eclipse.wst.common.snippets
org.eclipse.wst.common.snippets.tests
org.eclipse.wst.common.tests
org.eclipse.wst.common.tests.collector
org.eclipse.wst.common.tests.ui
org.eclipse.wst.common.ui
org.eclipse.wst.common.ui.properties
org.eclipse.wst.common.uriresolver
org.eclipse.wst.internet.cache
org.eclipse.wst.internet.cache.tests
org.eclipse.wst.validation
org.eclipse.wst.validation.infopop
org.eclipse.wst.validation.ui
Server
Component
org.eclipse.jst.server.core
org.eclipse.jst.server.core.tests
org.eclipse.jst.server.generic.core
org.eclipse.jst.server.generic.jboss
org.eclipse.jst.server.generic.jonas
org.eclipse.jst.server.generic.oc4j
org.eclipse.jst.server.generic.tests
org.eclipse.jst.server.generic.ui
org.eclipse.jst.server.installable
org.eclipse.jst.server.preview.adapter
org.eclipse.jst.server.tomcat.core
org.eclipse.jst.server.tomcat.core.tests
org.eclipse.jst.server.tomcat.ui
org.eclipse.jst.server.tomcat.ui.tests
org.eclipse.jst.server.ui
org.eclipse.jst.server.ui.doc.user
org.eclipse.jst.server.ui.infopop
org.eclipse.jst.server.ui.tests
org.eclipse.jst.server.websphere.core
org.eclipse.wst.internet.monitor.core
org.eclipse.wst.internet.monitor.ui
org.eclipse.wst.internet.monitor.ui.tests
org.eclipse.wst.server.core
org.eclipse.wst.server.core.tests
org.eclipse.wst.server.http.core
org.eclipse.wst.server.http.core.tests
org.eclipse.wst.server.http.ui
org.eclipse.wst.server.preview
org.eclipse.wst.server.preview.adapter
org.eclipse.wst.server.ui
org.eclipse.wst.server.ui.doc.user
org.eclipse.wst.server.ui.infopop
org.eclipse.wst.server.ui.tests
Source Editors
Component
org.eclipse.jst.jsp.core
org.eclipse.jst.jsp.core.tests
org.eclipse.jst.jsp.tests.encoding
org.eclipse.jst.jsp.ui
org.eclipse.jst.jsp.ui.infopop
org.eclipse.jst.jsp.ui.tests
org.eclipse.jst.standard.schemas
org.eclipse.wst.css.core
org.eclipse.wst.css.core.tests
org.eclipse.wst.css.tests.encoding
org.eclipse.wst.css.ui
org.eclipse.wst.css.ui.tests
org.eclipse.wst.dtd.core
org.eclipse.wst.dtd.ui
org.eclipse.wst.dtd.ui.infopop
org.eclipse.wst.dtd.ui.tests
org.eclipse.wst.dtdeditor.doc.user
org.eclipse.wst.html.core
org.eclipse.wst.html.core.tests
org.eclipse.wst.html.tests.encoding
org.eclipse.wst.html.ui
org.eclipse.wst.html.ui.infopop
org.eclipse.wst.html.ui.tests
org.eclipse.wst._javascript_.core
org.eclipse.wst._javascript_.ui
org.eclipse.wst._javascript_.ui.infopop
org.eclipse.wst.sse.core
org.eclipse.wst.sse.core.tests
org.eclipse.wst.sse.doc.user
org.eclipse.wst.sse.ui
org.eclipse.wst.sse.ui.infopop
org.eclipse.wst.sse.ui.tests
org.eclipse.wst.standard.schemas
org.eclipse.wst.xml.core
org.eclipse.wst.xml.core.tests
org.eclipse.wst.xml.tests.encoding
org.eclipse.wst.xml.ui
org.eclipse.wst.xml.ui.infopop
org.eclipse.wst.xml.ui.tests
org.eclipse.wst.xml.validation.tests
org.eclipse.wst.xmleditor.doc.user
org.eclipse.wst.xsd.core
org.eclipse.wst.xsd.ui
org.eclipse.wst.xsd.validation.tests
org.eclipse.wst.xsdeditor.doc.user
Web Services
Component
org.eclipse.jst.ws
org.eclipse.jst.ws.axis.consumption.core
org.eclipse.jst.ws.axis.consumption.core.tests
org.eclipse.jst.ws.axis.consumption.ui
org.eclipse.jst.ws.axis.creation.ui
org.eclipse.jst.ws.axis.infopop
org.eclipse.jst.ws.axis.ui.doc.user
org.eclipse.jst.ws.axis2.consumption.core
org.eclipse.jst.ws.axis2.consumption.ui
org.eclipse.jst.ws.axis2.core
org.eclipse.jst.ws.axis2.creation.core
org.eclipse.jst.ws.axis2.creation.ui
org.eclipse.jst.ws.axis2.ui
org.eclipse.jst.ws.consumption
org.eclipse.jst.ws.consumption.infopop
org.eclipse.jst.ws.consumption.ui
org.eclipse.jst.ws.consumption.ui.doc.user
org.eclipse.jst.ws.creation.ejb.ui
org.eclipse.jst.ws.creation.ui
org.eclipse.jst.ws.doc.user
org.eclipse.jst.ws.infopop
org.eclipse.jst.ws.tests
org.eclipse.jst.ws.uddiregistry
org.eclipse.jst.ws.ui
org.eclipse.wst.ws
org.eclipse.wst.ws.explorer
org.eclipse.wst.ws.infopop
org.eclipse.wst.ws.parser
org.eclipse.wst.ws.tests
org.eclipse.wst.ws.ui
org.eclipse.wst.wsdl
org.eclipse.wst.wsdl.tests
org.eclipse.wst.wsdl.tests.ui
org.eclipse.wst.wsdl.ui
org.eclipse.wst.wsdl.ui.doc.user
org.eclipse.wst.wsdl.validation
org.eclipse.wst.wsdl.validation.tests
org.eclipse.wst.wsi
org.eclipse.wst.wsi.tests
org.eclipse.wst.wsi.ui
org.eclipse.wst.wsi.ui.doc.user
Java EE Tools
Component
org.eclipse.jst.doc.isv
org.eclipse.jst.j2ee
org.eclipse.jst.j2ee.core
org.eclipse.jst.j2ee.core.tests
org.eclipse.jst.j2ee.doc.user
org.eclipse.jst.j2ee.infopop
org.eclipse.jst.j2ee.jca
org.eclipse.jst.j2ee.jca.ui
org.eclipse.jst.j2ee.navigator.ui
org.eclipse.jst.j2ee.tests
org.eclipse.jst.j2ee.ui
org.eclipse.jst.j2ee.web
org.eclipse.jst.j2ee.webservice
org.eclipse.jst.j2ee.webservice.ui
org.eclipse.jst.j2ee.xdoclet.runtime
org.eclipse.jst.jee
org.eclipse.jst.jee.ui
org.eclipse.jst.jee.web
org.eclipse.jst.servlet.tests
org.eclipse.jst.servlet.ui
org.eclipse.jst.servlet.ui.infopop
org.eclipse.wst.doc.isv
org.eclipse.wst.doc.user
org.eclipse.wst.web
org.eclipse.wst.web.ui
org.eclipse.wst.web.ui.infopop
org.eclipse.wst.webtools.doc.user
EJB Tools
Component
org.eclipse.jst.ejb.doc.user
org.eclipse.jst.ejb.ui
org.eclipse.jst.j2ee.ejb
org.eclipse.jst.j2ee.ejb.annotation.model
org.eclipse.jst.j2ee.ejb.annotations.emitter
org.eclipse.jst.j2ee.ejb.annotations.ui
org.eclipse.jst.j2ee.ejb.annotations.xdoclet
org.eclipse.jst.jee.ejb
JSF Component
org.eclipse.jst.jsf.common
org.eclipse.jst.jsf.common.ui
org.eclipse.jst.jsf.contentassist.tests
org.eclipse.jst.jsf.context.symbol.tests
org.eclipse.jst.jsf.core
org.eclipse.jst.jsf.core.tests
org.eclipse.jst.jsf.designtime.tests
org.eclipse.jst.jsf.doc.dev
org.eclipse.jst.jsf.doc.user
org.eclipse.jst.jsf.facesconfig
org.eclipse.jst.jsf.facesconfig.ui
org.eclipse.jst.jsf.metadata.tests
org.eclipse.jst.jsf.metadataprocessingtests2
org.eclipse.jst.jsf.standard.tagsupport
org.eclipse.jst.jsf.test.util
org.eclipse.jst.jsf.ui
org.eclipse.jst.jsf.ui.tests
org.eclipse.jst.pagedesigner
org.eclipse.jst.pagedesigner.jsf.ui
org.eclipse.jst.pagedesigner.jsp.core
JPT Component
org.eclipse.jpt
org.eclipse.jpt.core
org.eclipse.jpt.core.tests
org.eclipse.jpt.core.tests.extension.resource
org.eclipse.jpt.db
org.eclipse.jpt.db.ui
org.eclipse.jpt.doc.user
org.eclipse.jpt.gen
org.eclipse.jpt.ui
org.eclipse.jpt.utility
org.eclipse.jpt.utility.tests
Notice: This email message, together
with any attachments, may contain information of BEA Systems, Inc., its
subsidiaries and affiliated entities, that may be confidential, proprietary,
copyrighted and/or legally privileged, and is intended solely for the use of the
individual or entity named in this message. If you are not the intended
recipient, and have received this message in error, please immediately return
this by email and then delete it._______________________________________________
wtp-dev mailing
list
wtp-dev@xxxxxxxxxxx
https://dev.eclipse.org/mailman/listinfo/wtp-dev
Notice: This email message, together with any attachments, may contain information of BEA Systems, Inc., its subsidiaries and affiliated entities, that may be confidential, proprietary, copyrighted and/or legally privileged, and is intended solely for the use of the individual or entity named in this message. If you are not the intended recipient, and have received this message in error, please immediately return this by email and then delete it.
