Re: [sumo-user] Modify pedestrian dynamic model

Thank you Mr.Jakob
Let me briefly introduce my healthcare environment: individuals move with AGV. The AGVs are only to transfer materials in the environment (a flat floor) like the following picture. AGV might meet pedestrians who include: staff (S for short), visitor (V for short), patients - move like normal (N for short) and individuals with disabilities (D for short)


Therefore I need some improvement:
(i) in XML, the personFlow needs new attributes, for example: disable (a probability indicates the person is D or not). If a pedestrian is D type, he might have a stick or crutch or wheeled-chair or even he is bind.
(ii) In the intersection, D person (who has a slower velocity) might be carried by other S, V or even N people for crossing, especially as the D is moving in a crossway. After leaving the crossway, D person could be left alone.
(iii) A pedestrian will have different gap acceptance (a distance between person to the AGV). If the distance is too short, he/she would decide to stay at the waiting area.

The gap acceptance of a pedestrian depends on yielding of vehicle (too loud or not), healthy of the person as well as the number of AGV's platoon
Looking at the code of Omnet++ and SUMO, I still don't know which files to modify. If it is too difficult to change the code, perhaps I have no choice but to use a quick and dirty hack to get my purpose.
Thank you in advance

On Sun, Nov 20, 2022 at 9:51 PM Jakob Erdmann <namdre.sumo@xxxxxxxxx> wrote:
Some comments:
- the paper ""Modelling pedestrian dynamics in SUMO" doesn't describe the whole set of vehicle/pedestrian interactions that are currently implemented
- the SUMO team is currently engaged with the integration of "social force" style pedestrian models by way of JuPedSim (jupedsim.org), https://github.com/eclipse/sumo/tree/jupedsim

Can you describe the interactions that you need to simulation in more detail?



Am So., 20. Nov. 2022 um 14:41 Uhr schrieb Thanhnt Nguyen <thanhnt.fit@xxxxxxxxx>:
Dear all
As reading the papers: "Modelling pedestrian dynamics in SUMO" and "Pedestrian Simulation In SUMO Through Externally Modelled Agents" I notice that the current pedestrian model in SUMO is very simple.
In my work, I need a pedestrian model which reflects a healthcare environment. In this model, I intend to implement interaction between vehicles (Automated Guided Vehicle) as well as individuals with disabilities
I still don't know how to implement a new pedestrian model in SUMO, could I need to modify the code of Viens?
Does anyone have a hint for me by chance?
Thank you in advance
