Hi all,
To complete the
discussion, the duplicated features are those generated by
the “extends relationship” : let’s consider a stereotype
“Child” that inherits from Stereo1 and Stereo2 [1]. Both of
them extend the same “Element” metaclass.
In practice ecore
generates a “base_Element” eRef for both Stereo1 and
Stereo2.
In theory, those
features have the same meaning and they should be merged in
Child.
By default, with the
“discard” option for duplicated feature inheritance, the UML
to Ecore generator directly removes the Stereo2 inheritance
[2].
“Process” option
preserves the inheritance, but renames the one of the
features [3].
“Ignore” option
preserve feature names and inheritance, but a model
validation error occurs [4].
Last, “Report” option
directly stops the process when the UML model loaded [5].
I don’t know if it’s
a known issue and if there is an existing solution?
(feature redefinition?)
[1]
[2]
[3]
[4]
[5]
-----Message
d'origine-----
De : mdt-papyrus.dev-bounces@xxxxxxxxxxx
[mailto:mdt-papyrus.dev-bounces@xxxxxxxxxxx] De la part de
MAGGI Benoit
Envoyé : mardi 28 mars 2017 11:39
À : Papyrus Project list <mdt-papyrus.dev@xxxxxxxxxxx>
Objet : [PROVENANCE INTERNET] Re: [mdt-papyrus.dev] multiple
inheritance in profile
Hi Ed,
Gery is currently working on the BPMN
Papyrus DSML, you may find all sources in this eclipse
repository [1].
I think it's quite natural for him to
use this mailing list for such tricky dev question.
The root issue is that OMG BPMN profile
is indeed using multi-inheritance and same property name [2].
(IMHO: very bad idea, but I didn't check
if it's valid for an UML profile)
Maybe it should be reported as OMG bug?
Regards,
Benoit
1:
https://git.eclipse.org/c/papyrus/org.eclipse.papyrus-bpmn.git/
2: BPMNActivity extends InteractionNode
and BaseElement BaseElement and InteractionNode both have a
base_Element property.
-----Message d'origine-----
De :
mdt-papyrus.dev-bounces@xxxxxxxxxxx
[mailto:mdt-papyrus.dev-bounces@xxxxxxxxxxx]
De la part de Ed Willink Envoyé : mardi 28 mars 2017 11:22 À :
Papyrus Project list <mdt-papyrus.dev@xxxxxxxxxxx>
Objet : Re: [mdt-papyrus.dev] multiple inheritance in profile
Hi
This is the Papyrus developers list.
Please use the Papyrus forum for Papyrus usage questions. Use
the UML2 forum for UML questions.
You haven't provided a repro so I may be
misunderstanding what is nasty.
base_XXX/extension_XXX is effectively
reserved for use by the Stereotype implementation mechanics.
Very bad practice to re-use it. Imperfect tooling may get
confused.
Duplicate feature names are prohibited
in Ecore and UML. In Ecore (for the reified Stereotype) you
would be in trouble. However UML provides a redefinition
capability. This should be used to break the conflict. I've
only used it in some superficial OCL test cases, so you may
have some bugs to circumvent. Raise Bugzillas with fulll
project repros.
Regards
Ed Willink
On 28/03/2017 09:53, DELOGE Gery 249233
wrote:
> Hi,
>
> I had annoying exceptions in BPMN.
The root cause was an issue in BPMN profile generated code
with multiple inheritance.
> A stereotype inherits from two
parents who have each a property named with the same name.
> Basically BPMNActivity inherits
from InteractionNode and from BaseElement who have both a
base_element attribute.
>
> Initial configuration was UML2
generator
(xmlns:genmodel="http://www.eclipse.org/uml2/2.2.0/GenModel in
genmodel file) and DUPLICATE_FEATURE_INHERITANCE set to
DISCARD.
> In this case, the inheritance from
InteractionNode is not present in generated code and effect is
IllegalArgumentException.
>
> First test was renaming
base_element attribute in InterractionNode and keeping
DUPLICATE_FEATURE_INHERITANCE to discard.
> Code was generated without error
and multiple inheritance is fine.
>
> Second test was setting
DUPLICATE_FEATURE_INHERITANCE to Process. In that case
multiple inheritance is generated correctly but I have one
error in generated code in a switch case in eIsSet method
> case
BPMNProfilePackage.INTERACTION_NODE__BASE_ELEMENT:
> return
isSetBase_Element();
> INTERACTION_NODE__BASE_ELEMENT
cannot be resolved or is not a field
> Commenting this case and everything
look fine.
>
> Does anyone already have this issue
?
> What is the best solution ?
>
> Cheers,
> Géry
>
>
>
