Re: [tractusx-dev] Update TRG 5.05 - Aligning (more) standards Helm char

[Florian Rusch <F.Rusch@xxxxxxxxxx>]

Hello all together,



as someone who uses some of the different helm charts, I could suggest the following points for alignment:



• Use the root node as the level, where configurations for the service should be placed. E.g. some of our projects like the DTR put all the values for the service under a specific node in the values for the service. In case of the DTR it’s the `registry:` node (see [1]). This uneccessary additonal indentation level which brings in my eyes no further advantage.
• All configurations for dependencies (like databases etc) should be put unter the node, that is named like the alias of the dependency.
• Aligned handling of environment variables: At the EDC I untroduced in the past the possibility to provide them directly as key-value pairs, via *KeyRef or by mounting directly secrets and configmaps (see [2]).
• Usage of NetworkPolicies, HorizontalPodAutoscaler, ServiceMonitor (Gathering of Metrics via Prometheus)
• Usage of Labels and annotations, as well as the “default” functions in the `_helpers.tpl` (see [3]) to ensure, that the same chart can be deployed multiple times in the same k8s namespace.
• Introduce the usage of global configurations (see [4]) to make it easiert to configure multiple different services together in an umbrella helm chart.





[1]: https://github.com/eclipse-tractusx/sldt-digital-twin-registry/blob/f1f4432c20dc34bb3fb9030c186f177f63c682b0/charts/registry/values.yaml#L29

[2]: https://github.com/eclipse-tractusx/tractusx-edc/blob/d3cbf44e0d92d643a5903043a1f6aed644bc05f3/charts/tractusx-connector/values.yaml#L173-L196

[3]: https://github.com/eclipse-tractusx/sldt-digital-twin-registry/blob/f1f4432c20dc34bb3fb9030c186f177f63c682b0/charts/registry/templates/_helpers.tpl#L1-L48

[4]: https://helm.sh/docs/chart_template_guide/subcharts_and_globals/#global-chart-values



Viele Grüße/Best regards

Florian Rusch
Senior DevSecOps Specialist

cluetec GmbH
Wilhelm-Schickard-Str. 9
76131 Karlsruhe | Deutschland
Telefon: +49 721 83179-226

Mobile: +49 160 996 856 80

F.Rusch@xxxxxxxxxx | www.cluetec.de

Geschäftsführer: Matthias Helferich, Thomas Rieger, Hermann Schäfer
Handelsregister: Mannheim HRB 109205, USt-ID-Nr.: DE213118929







From: tractusx-dev <tractusx-dev-bounces@xxxxxxxxxxx> on behalf of carsten.lenz--- via tractusx-dev <tractusx-dev@xxxxxxxxxxx>
Date: Friday, 1. March 2024 at 10:49
To: tractusx-dev@xxxxxxxxxxx <tractusx-dev@xxxxxxxxxxx>
Cc: carsten.lenz@xxxxxxxxxxxxxxxxx <carsten.lenz@xxxxxxxxxxxxxxxxx>
Subject: [tractusx-dev] Update TRG 5.05 - Aligning (more) standards Helm chart values.yaml

Achtung: Diese E-Mail stammt von einem externen Absender. Bitte vermeide es, Anhänge oder externe Links zu öffnen



Hey Community,



We’re thinking about to extend our existing TRG 5.05 – Chart Values [1] and align more defaults across existing Eclipse Tractus-X product Helm charts. As we as a community gained plenty of experience with Helm charts for quite some time now, I wanted to ask you for additional input what we could align of in this TRG to have the same settings across our Helm charts.



What comes into my mind (unordered list without precedence):



• Database
  How to address internal (deployed with the Helm chart) and external DB.
• IAM/IDP/Keykloak
  Would be nice to have a sane default?!
• Ingress
  Having the same commented ingress block with possible application specific settings.
• securityContex/resources/livenessProbe/readynessProbe/…
• …



What do you think what would be worth to align on across all available Helm charts and add to TRG 5.05?

Chers
Carsten



[1] TRG 5.05 – Chart Values
https://eclipse-tractusx.github.io/docs/release/trg-5/trg-5-05

--
