Displaying field/attribute names in Dominator Tree [message #1066763]

Thu, 04 July 2013 05:17

Eclipse User

Not sure there is a big community in Stackoverflow so I will repeat it here.

How do I display the field/attribute names in the Dominator Tree? The information is cleary available if you look at the Inspector on the left-hand side.

Is there a setting somewhere which will allow me to display this information on the dominator tree tab?

Attachment: matt.png
(Size: 56.17KB, Downloaded 411 times)

Re: Displaying field/attribute names in Dominator Tree [message #1066826 is a reply to message #1066763]

Thu, 04 July 2013 10:15

Eclipse User

The references in the dominator tree do not correspond one to one the real references. You may have a parent A and child B in the dom. tree, such that the parent does not have a direct reference to the child object; there may be a long chain of other references between them. The dominator tree expresses only, that all paths from the GC roots to B (the child object) go through A.
Therefore no field name is displayed. Use the path from GC roots to the child object to examine the real path/reference chain.

Krum
