| Re: Exported class diagrams missing text [message #986218 is a reply to message #986192] |
Mon, 19 November 2012 08:49   |
Eclipse User |
|
|
|
Hi, Andy,
What file format are you exporting to? And on what platform?
I've found that GMF can't reliably export PNG on Mac OS X. Text is one
of the problems. I use the JPG option exclusively on Mac.
Cheers,
Christian
On 2012-11-19 11:49:25 +0000, Andy Key said:
> I have a few class diagrams in a model that I would like to export as
> an image. When I try either clicking on the model and the "Export all
> diagrams..." option, or right-clicking inside a diagram and "File ->
> Save as image file", the images are generated. However, most of the
> labels in the classes are missing, ie. the properties and operations
> are not present in the exported diagrams - except of course for one
> particular property. At times, not even the class names are present,
> just the applied stereotypes. No exceptions are written to
> .metadata/.log when running the export. It seems to me that it is
> attempting to render the properties, and runs into an exception which
> is caught and ignored, without being logged (just a theory of course).
>
> Has anyone else seen this?
>
>
> <image>
|
|
|
| Re: Exported class diagrams missing text [message #986362 is a reply to message #986216] |
Tue, 20 November 2012 04:00 |
| Eclipse User |
|
|
|
@Camille:
I am using the latest release of Topcased, 5.2.0, which has Papyrus 0.8.2.v201204031124, at least according to the eclipse installation details page. Running Ubuntu 12.04 64-bit, OpenJdk 1.6.0_24-b24. Was trying to save the diagrams as PNG.
@Christian:
It appears that PNG output on 64-bit Ubuntu is also borked. JPEG exported correctly with all text. Thanks for the tip!
|
|
|
